Working Principle

Flaked materials are fed into the top of the cooker and move downward through multiple conditioning layers under gravity.

Each layer is equipped with steam jacket heating for indirect heat transfer. In the first layer, direct steam injection can be applied for rapid conditioning.

Material is continuously mixed by agitators to ensure uniform heat and moisture distribution. Residence time is controlled by adjustable discharge gates between layers.

The combined action of heat and moisture adjusts material plasticity and prepares it for downstream pressing or solvent extraction.

Design Features

Multi-layer vertical structure for continuous processing
Combination of indirect steam jacket heating and optional direct steam injection
Independent agitation system in each layer for uniform mixing
Adjustable discharge gates for residence time control
Vapor exhaust system on each layer (except first layer)
Heavy-duty gear transmission system for stable operation
Compact vertical layout for space-saving installation
Customizable number of layers and heating configuration

Engineering Benefits

Improves flake plasticity for pressing and extraction
Promotes effective oil cell rupture in conditioning stage
Ensures stable moisture and temperature control
Enhances downstream extraction efficiency
Improves crude oil yield and consistency
Stabilizes overall pretreatment process performance
Supports continuous large-scale plant operation

Process Position

Cleaning → Crushing → Flaking → Cooking (Vertical Cooker) → Pressing / Solvent Extraction

The Vertical Cooker is a core conditioning unit in modern oilseed processing plants. It ensures stable thermal and moisture treatment of flaked materials, creating optimal conditions for efficient oil recovery and reliable downstream operation.
